TMV-MP-3

X Travel 31 in.
Y Travel 15.5 in.
Z Travel 5 in.
Taper, HP R-8, 3 hp
Spindle Variable Speed
Request a Quote
Download Brochure
Overview
Features
Specs
Accessories

Overview

This is a simple, easy to use 3 axes CNC control vertical mill. Ball screws and servo drives are installed for longitudinal and cross travel. 3 axes Digital Readout System are installed on the table, saddle and quill. The Millpwr G2 CNC has G code and conversational type programming . The CNC system is built on the top quality SHARP vertical mills frame.

  • 10 x 54” table, 15.5 x 31x 5” travel, vari speed 3 HP, R-8 spindle
  • AcuRite Millpwr G2 CNC 3 axes control (Longitudinal, Cross)
  • G code and conversational type programming
  • 3 axes precision ball screws
  • Safety handwheels
  • Auto lube system
  • 3 axes Digital Readout System (table, saddle, quill)

Features

Millpwr G2 Turnkey CNC System w/Software and Hardware

Dimension Functions:

  • ABS/INC, POLAR/CARTESIAN, INCH/METRIC.

Programming:

  • PROGRAM IN/OUT, POSITION/DRILL, MILL LINES, MILL ARC, BLEND (CORNER RADIUS)
  • HOLES (BOLT CIRCLE, RECTANGULAR ARRAY, RECTANGULAR FRAM, LINE),
  • CIRCLE (POCKET, FRAM, RING), RECTANGLE (POCKET, FRAME, SLOT, FACING) 9,999 STEPS OF PROGRAM SIZE

Special Features:

  • CUSTOM POCKETS, REPEAT, ROTATE, MIRROR IMAGE.

Run Options:

  • SINGLE STEP, DRY RUN, GRAPHICS ONLY, MANUAL POSITIONING.

Calculator Functions:

  • GEOMETRY, TRIG.

HARDWARE

Operator Console:

  • EASY TO USE FORMAT. CONVERSATIONAL ENGLISH.  THREE DIMENSIONAL HARD KEYS.  10” FLAT PANEL, COLOR LCD DISPLAY.  REMOTE STOP/GO SWITCH.

Controller Cabinet:

  • HEAVY DUTY ENCLOSURE MODULAR CONSTRUCTION, 1 GHz Intel Celeron MICROPROCESSOR.
  • USB AND RS232 INTERFACE
  • 1” HIGH RESOLUTION DISPLAY WITH 3 D GRAPHICS
  • 115VAC – 20 AMPS

Specs

Capacity

Inch

Metric

Table Size

10 x 50 in.

254 x 1270 mm

T-slots (No., Size, Pitch)

3, 5/8, 2.5 in.

3, 16, 63.5 mm

Table Travel : X Longitudinal

31 in.

787 mm

Table travel : Y Cross

15.5 in.

393 mm

Quill travel: Z Vertical

5 in.

127 mm

Ram Travel

18.5 in.

470 mm

Knee travel : Vertical

15.3 in.

388.62 mm

Spindle Center to Column

9.8 - 28.3 in.

250 - 720 mm

Spindle Nose to Table Top

1.6 - 16.9 in.

40.64 - 429.26 mm

Head, Spindle

Inch

Metric

Spindle Nose TaperR-8 NT-40
Spindle Variable Speed Range

60 - 4500 rpm

60 - 4500 rpm

Spindle Motor (220V/440V)

3 HP

2.25 KW

Quill Feed (Inch/Rev)(3 speeds)

0.0015, 0.003, 0.005 in.

0.0381, 0.0762, 0.127 mm

Head Tilt Angle (L/R)90°90°
Head Tilt Angle (Up/Down)45°45°

General

Inch

Metric

Floor Area (W x D x H)

7.08 x 6.66 x 7.5 ft.

2.15 x 2.02 x 2.28 M

Approximate Weight

3500 lbs.

1587 kg

Power Consumption (220V)3 KVA/15 amps5 KVA/25 amps
Power Consumption (440V)3 KVA/7.5 amps5 KVA/12.5 amps

All specifications subject to change without notice. Please call to verify.

Accessories

Standard Accessories

  • Millpwr G2 3 axes CNC system
  • 3 axes ball screws and servo drives
  • Auto lube system
  • 3 axes Digital Readout system
  • Cross Way cover

Optional Accessories

  • NT#30 SPINDLE IN LIEU OF NT#40
  • Acu-Rite electrical edge finder
  • 6” “Kurt” Vise with Swivel Base
  • Drill chuck
  • Sharp Power Kneel
  • Coolant System with Chip Pan At Base
  • Power Draw Bar
  • R-8 Collet (Set of 11) – 1/8” – 3/4” by 1/16”
  • Clamping Kit (52 pcs/steel rack)
  • Halogen Work light
  • Riser block 6
  • 440 V transformer
  • 4th axes Digital Readout System (on knee)
