current specials
5-axis simultaneous vmc
svx-300-f
$2,711 Per Month
- IN STOCK FOR IMMEDIATE DELIVERY -
- FANUC 31iB5, 10.4″ LCD color screen
- Travel: X/Y/Z: 30″/ 23.6″/ 19.7″
- Max Working Load: 330 lbs.
- Trunnion Table: A/C Diameter: 9.8″/ 11.8″, A/C Degree: -120 to +30/360
- Roller Cam type trunnion table
- Spindle: 12K Rpm, CAT 40 Big Plus, Direct Driven, 15 HP Motor
- ATC: Side Mount 24 Tools
- Position Accuracy: X/Y/Z (+/- 0.0002″)
- Repeatability Accuracy: X/Y/Z (+/- 0.00012″)
- Rapid Traverse X/Y/Z 1417 ipm
- A/C Axis Position Accuracy: +/- 15 Arc Sec
- A/C Axis Repeatability: 6 Arc Sec
5-axis simultaneous vmc
svx-500-f
$4,891 Per Month
- IN STOCK FOR IMMEDIATE DELIVERY -
- FANUC 31iB5, 10.4″ LCD color screen
- Linear Roller Pack Way Construction
- Travel: X/Y/Z: 30″/ 23.6″/ 19.7″, A/C Axis: -110-20°/360°
- Max Working Piece: 770 lbs.
- Trunnion: 19.7″ Dia. Cam Roller Type, Zero Backlash
- Rapid Traverse feed rate on X and Y axes reaches 2,362 in/min
- 15K RPM, CAT 40 Big Plus, 25 HP, with Oil Chiller
- ATC: 30 Tools (60T optional)
- Box-in-Box Construction
- Position Accuracy: X/Y/Z (+/- 0.0015) (0.00006″)
- Repeatability Accuracy: X/Y/Z (+/- 0.0015) (0.00006″)
- A/C Axis Position Accuracy: A +/- 6, C +/- 5 Arc Sec
- Chip conveyor situated at back of machine
gear head box way vmc
svg-6336A-f
$3,486 Per Month
- IN STOCK FOR IMMEDIATE DELIVERY -
- FANUC Oi-MF, 10.4″ LCD color screen
- Travel: X/Y/Z: 63″/ 43″/ 27.5″
- Table: 71″ x 31.5″
- 4 Box Ways (Hardened and Ground)
- Spindle: 6K rpm, CAT 50 Geared Head, 35 HP Motor
- 40 Position Automatic Tool Changer
- Position Accuracy: X/Y/Z (0.0003″ within 12″)
- Repeatability Accuracy: X/Y/Z (+/- 0.0002 within 12″)
- Rapid Traverse X-590/Y-590/Z-472
- Machine Weight 35,274 lbs.
CNC Cylindrical Grinder
OD-1320-2X
$1,782 Per Month
- IN STOCK FOR IMMEDIATE DELIVERY -
- FANUC Oi-TF CNC control
- Max grinding diameter 12.6″ (Model OD-1320-2X)
- Distance bet centers 20″ (Model OD-1320-2X)
- Wheel head rotates on BABBIT bearings, a combination of hydrostatic and hydrodynamic bearings surrounded by high pressure oil film eliminating metal to metal contact thus providing vibration dampening.
- Table moves on hydrodynamic slideways that makes table movement smooth and stable
- X axis is equipped with linear scale with 0.00001″ resolution for high precision movement
- Grinding wheel has constant surface speed function.
